Model

   Model

   Model

   Model

DC Output voltage

5V

7.5V

12V

15V

24V

48V

Output voltage range(Note:2)

±2%

±1%

±1%

±1%

±1%

±1%

Rated output current

22A

15A

10A

8A

5A

2.5A

Output current range

0~22A

0~15A

0~10A

0~8A

0~5A

0~2.5A

Wave and noise(Note:3)

75mVp-p

100mVp-p

60mVp-p

60mVp-p

50mVp-p

50mVp-p

Inlet stability(Note:4)

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

Load stability(Note:5)

±1%

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

DC output power

110W

115W

120W

120W

120W

120W

Efficiency

76%

78%

80%

81%

83%

84%

Adjustable range for DC voltage

±10%

±10%

±10%

±10%

±10%

±10%

AC input voltage range

85~132VAC/170~264VAC selected by switch 47~63Hz,248~370VDC

Input current

2.4A/115V 1.2A/230V

AC Inrush current

Cold-start current 30A/115V 60A/230V

Leakage current

<1mA/240VAC

Overload protection

105 ~ 150%  Protection type :pulsing hiccup shutdown Reset: auto recovery.

Temperature coefficient

±0.03%/°C(0~50°C)

Setup, rise, hold up time

200ms, 100ms, 30ms

Vibration

10~500Hz, 2G 10min,/1 cycle. Period for 60min,Each axes

Withstand voltage

I/P-O/P:1.5KVAC I/P-FG:1.5KVAC  O/P-FG:0.5KVAC

Isolation resistance

I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC

Working temperature and humidity

-10°C~+60°C(Refer to output load derating curve),20%~90%RH

Store temperature and humidity

-20°C~+85°C,10%~95%RH

Safety standards

Meet UL1012 requirement(Not apply for the mark)

EMC standards

Meet FCC PART 15J Conduction class B

Note

1. The parameter under the testing condition : 230vAC input ,rated load,25°C70% RH. Temperature.

2. Tolerance the setting tolerance, circuit stability and load stability.(Note:5).

3. Wave test: adopting "A12"double wire for 20MHz, and 0.1 UF&47UF capacitor short-circuit for interrupting.

4. Inlet voltage stability test : the lowest voltage will be up to the highest voltage when the circuit overload.

5. Load stability test: The load is from 0% to 100%.
