Model

Specification

S-150-5

S-150-7.5

S-150-9

S-150-12

S-150-13.5

S-150-15

S-150-24

S-150-27

S-150-48

  DC Output voltage

 5V

 7.5V

9V

 12V

13.5V

  15V

 24V

   27V

   48V

  Output voltage range(Note:2)

   ±2%

  ±1%

±1%

  ±1%

±1%

  ±1%

  ±1%

  ±1%

  ±1%

  Rated output current

  30A

 20A

16.7A

  12.5A

  11.2A

  10A

  6.5A

  5.6A

 3.2A

  Output current range

  0~30A

  0~20A

0~16.7A

  0~12.5A

0~11.2A

  0~10A

  0~6.5A

  0~5.6A

  0~3.2A

  Wave and noise(Note:3)

    150mVp-p

150mVp-p

120mVp-p

  100mVp-p

100mVp-p

  100mVp-p

  100mVp-p

  100mVp-p

  75mVp-p

  Inlet stability(Note:4)

   ±0.5%

  ±0.5%

±0.3%

  ±0.3%

±0.3%

  ±0.3%

  ±0.2%

  ±0.2%

  ±0.2%

  Load stability(Note:5)

    ±0.5%

  ±0.5%

±0.3%

   ±0.3%

±0.3%

  ±0.3%

   ±0.2%

   ±0.2%

   ±0.2%

  DC output power

  150W

  150W

150.3W

  150W

 151.2W

  150W

  156W

  151.2W

  153.6W

  Efficiency

   80%

  80%

80%

  82%

83%

  84%

  85%

  86%

  87%

  Adjustable range for DC voltage

    4.5~5.5V

  6~8.3V

8~10.4V

  10.6~13.2V

12~15V

  13.5~16.5V

  21~28V

  24~30V

  43~53V

  AC input voltage range

         85~132VAC/176~264VAC selected by switch 47~63Hz, 248~370VDC

  Input current

         3.2A/115V  1.6A/230V

  AC Inrush current

         Cold-start current 30A/115V  60A/230V

  Leakage current

         <3.5mA/240VAC

Overload protection

         105% ~ 150% Type: cut down output  Reset: auto recovery.

Over-voltage protection

         115%~135%

  Temperature coefficient

         ±0.03%/°C(0~50°C)

  Setup, rise, hold up time

         100ms, 50ms, 20ms

  Vibration

         10~500Hz, 2G 10min,/1 cycle. Period for 60min, Each axes

  Withstand voltage

         I/P-O/P:1.5KVAC  I/P-FG:1.5KVAC  O/P-FG:0.5KVAC

  Isolation resistance

         I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC

  Working temperature and humidity

         -10°C~+60°C(Refer to output derating curve), 20%~90%RH

  Store temperature and humidity

         -20°C~+85°C, 10%~95%RH

  Safety standards

         UL 1950 TUV EN60950 Approved

  EMC standards

         CISPR22(EN 5022), IEC1000-4-2,3,4 IEC1000-3-2 Verification

Note:

1. The parameter under the testing condition: 230VAC input, rated load, 25°C70% RH. Temperature.
2. Tolerance: Including setting tolerance, circuit stability and load stability. (Note: 5).
3. Wave test: Adopting “A12” double wire for 20MHz, and 0.1 UF&47UF capacitor short-circuit for interrupting.
4. Inlet voltage stability test: the lowest voltage will be up to the highest voltage when the circuit overload.
5. Load stability test: The load is from 0% to 100%.
