Model

 Specification

S-150-7.5

S-150-9

S-150-12

S-150-13.5

S-150-15

S-150-24

DC Output voltage

7.5V

9V

12V

13.5V

15V

24V

Output voltage range(Note:2)

±1%

±1%

±1%

±1%

±1%

±1%

Rated output current

20A

16.7A

12.5A

11.2A

10A

6.5A

Output current range

0~20A

0~16.7A

0~12.5A

0~11.2A

0~10A

0~6.5A

Wave and noise(Note:3)

150mVp-p

120mVp-p

100mVp-p

100mVp-p

100mVp-p

100mVp-p

Inlet stability(Note:4)

±0.5%

±0.3%

±0.3%

±0.3%

±0.3%

±0.2%

Load stability(Note:5)

±0.5%

±0.3%

±0.3%

±0.3%

±0.3%

±0.2%

DC output power

150W

150.3W

150W

151.2W

150W

156W

Efficiency

80%

80%

82%

83%

84%

85%

Adjustable range for DC voltage

6~8.3V

8~10.4V

10.6~13.2V

12~15V

13.5~16.5V

21~28V

AC input voltage range

85~132VAC/176~264VAC selected by switch 47~63Hz,248~370VDC

Input current

3.2A/115V 1.6A/230V

AC Inrush current

Cold-start current 30A/115V 60A/230V

Leakage current

<3.5mA/240VAC

Overload protection

105 ~ 150%  Protection type :pulsing hiccup shutdown Reset: auto recovery.

Over-voltage protection

115%~135% Protection type :shut off output

Temperature coefficient

±0.03%/°C(0~50°C)

Setup, rise, hold up time

100ms, 50ms, 20ms

Vibration

10~500Hz, 2G 10min,/1 cycle. Period for 60min,Each axes

Withstand voltage

I/P-O/P:1.5KVAC I/P-FG:1.5KVAC  O/P-FG:0.5KVAC

Isolation resistance

I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC

Working temperature and humidity

-10°C~+60°C(Refer to output load derating curve),20%~90%RH

Safety standards

UL 1950 TUV EN60950 Approved

EMC standards

CISPR22(EN 5022),IEC1000-4-2,3,4 IEC1000-3-2 Verification

Note

1. The parameter under the testing condition : 230vAC input ,rated load,25°C70% RH. Temperature.

2. Tolerance the setting tolerance, circuit stability and load stability.(Note:5).

3. Wave test: adopting "A12"double wire for 20MHz, and 0.1 UF&47UF capacitor short-circuit for interrupting.

4. Inlet voltage stability test : the lowest voltage will be up to the highest voltage when the circuit overload.

5. Load stability test: The load is from 0% to 100%.
