Model

Specification

  S-500-5

  S-500-12

  S-500-15

  S-500-24

  S-500-48

 DC Output voltage

5V

12V

15V

24V

48V

 Output voltage range(Note:2)

±2%

±1%

±1%

±1%

±1%

 Rated output current

80A

40A

32A

20A

10.4A

 Output current range

0~80A

0~40A

0~32A

0~20A

0~10.4A

 Wave and noise(Note:3)

75mVp-p

120mVp-p

150mVp-p

240mVp-p

240mVp-p

 Inlet stability(Note:4)

  0.5%

  ±1%

  ±1%

  ±1%

  ±1%

 Load stability(Note:5)

  ±3%

  ±1%

  ±1%

  ±0.3%

  ±0.3%

  DC output power

  400W

  480W

  480W

  480W

  500W

  Efficiency

  80%

  83%

  84%

  86%

  87%

  Adjustable range for DC voltage

  ±10%

  ±10%

  ±10%

  ±10%

  ±10%

  AC input voltage range

      100~132VAC/190~240VAC 250~340VDC

  Input current

      5A/230V

  Power factory

      0.65 - 0.75

  AC Inrush current

      46A/230V

  Leakage current

      < 3.5mA/240VAC

  Overload protection

      105%-150% Type: cut down output. Reset: auto recovery.

  Over-voltage protection

      120%-150%

  High-temperature protection

      ERH3≥ 65°C~70°CFan on, ≤55°C~60°CFan off, ≥80°C~85. Cut off output (5-15V)~(24-48V)

  Temperature coefficient

      ±0.03%/°C

  Setup, rise, hold up time

      1s, 100ms, 50ms

  Vibration

      10~500Hz, 2G 10min,/1 cycle. Period for 60min, Each axes

  Withstand voltage

      I/P-O/P:1.5KVAC  I/P-FG:1.5KVAC  O/P-FG:0.5KVAC

  Isolation resistance

      I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC

  Working temperature and humidity

      (-10°C)~+60°C, 10%~95%RH

  Store temperature and humidity

      (-20°C)~+85°C, 10%~95%RH

  Safety standards

      GB4949, UL60950, EN60950

  EMC standards

      According to GB9254 EN55022 EN55024 A level design

Note:

1. The parameter under the testing condition: 230VAC input, rated load, 25°C70% RH. Temperature.
2. Tolerance: Including setting tolerance, circuit stability and load stability. (Note:5).
3. Wave test: Adopting “A12” double wire for 20MHz, and 0.1 UF&47UF capacitor short-circuit for interrupting.
4. Inlet voltage stability test: the lowest voltage will be up to the highest voltage when the circuit overload.
5. Load stability test: The load is from 0% to 100%.
6. C3, 4 must be knocked down.
